PRO510XL
Compact Mobile CB Radio
As part of Uniden's Professional Series, the PRO510XL CB radio offers high-performance 40-channel operation in a compact, ultra-mobile radio. This model operates on any of the 40 AM frequencies authorized by the FCC, and its S/RF meter and red-lit LED indicators help you monitor activity at a glance. A built-in noise limiter and ANL switch and squelch control fine-tune performance and eliminate noise, and the front-positioned microphone has an extra- long, coiled cord for convenient use.
$69.99

Automatic Noise Limiter

Superheterodyne Circuit

Signal/RF Meter



Details
Width | 4.5" |
---|---|
Height | 1.375" |
Depth | 6.75" |
Weight | 1lb 9oz |
Input Voltage | 13.8 V DC nom. (+ or - ground) |
Power Output | 4 Watts |
Frequency Control | Phase Locked Loop (PLL) synthesizer |
Frequency Range | 26.965MHz to 27.405 MHz |
Operating Temperature | -30ºC to +50ºC |
Antenna Connector | UHF, SO-239 |
Audio Output Power | 7 watts max. into 8 ohms |
Automatic Gain Control (AGC) | Less than 10dB change in audio output for inputs from 10 to 50,000 microvolts |
RF Gain Control | Adjustable for optimum reception |
Squelch | Adjustable; threshold less than 1μV |
I.F. Frequency | Double Conversion Superheterodyne •1st 10.692 MHz •2nd 450 kHz |
Receiver Sensitivity | 0.5μV for 10 dB; (S + N) /N typical (limit 1.0μV) |
